- Place of Origin: Shandong
- Brand Name: Liaocheng Ote Bearing Co.,LTD
- Model Number: 22206
- Weight: 0.287 kg
Spherical bearings are used in countless applications, wherever rotational motion must be allowed to change the alignment of its rotation axis. A prime example is a tie rod on a vehicle suspension. The mechanics of the suspension allow the axle to moveup and down, but the linkages are designed to control that motion in one direction only and they must allow motion in the other directions. Spherical bearings have been used in car suspensions, driveshafts, heavy machinery, sewing machines, and many other applications.
1.OEM service . We can design and produce it based on your requirment.
2.The different package can be choose.
3.12 months warranty after shippment.
4.Long life maintenance service for the products.
5.Free samples
- Place of Origin: Shandong
- Brand Name: Liaocheng Ote Bearing Co.,LTD
- Model Number: 22206
- Weight: 0.287 kg
Principal dimensions | Basic load rating | Fatigue load limit | Speed ratings | Designation | |||||
dynamic | static | Reference speed | Limiting speed | ||||||
d | D | B | C | C 0 | P u | ||||
mm | kN | kN | r/min | ||||||
20 | 52 | 18 | 49.9 | 44 | 4.75 | 13000 | 17000 | 22205/20 E | |
25 | 52 | 18 | 49.9 | 44 | 4.75 | 13000 | 17000 | 22205 | EK |
25 | 52 | 23 | 49.9 | 44 | 4.75 | 6100 | BS2-2205-2RS/VT143 | ||
25 | 62 | 17 | 49.1 | 41.5 | 4.55 | 9300 | 12000 | 21305 | CC |
25 | 52 | 18 | 49.9 | 44 | 4.75 | 13000 | 17000 | 22205 | E |
30 | 62 | 20 | 66.1 | 58.5 | 6.4 | 10000 | 14000 | 22206 | EK |
30 | 62 | 25 | 66.1 | 58.5 | 6.4 | 5100 | BS2-2206-2RS/VT143 | ||
30 | 62 | 20 | 66.1 | 58.5 | 6.4 | 10000 | 14000 | 22206 | E |
30 | 72 | 19 | 65.7 | 61 | 6.8 | 8200 | 10000 | 21306 | CCK |
30 | 72 | 19 | 65.7 | 61 | 6.8 | 8200 | 10000 | 21306 | CC |
35 | 80 | 21 | 79.2 | 72 | 8.15 | 7300 | 9500 | 21307 | CC |
35 | 72 | 28 | 88.8 | 83 | 9.15 | 4300 | BS2-2207-2RS/VT143 | ||
35 | 72 | 23 | 88.8 | 83 | 9.15 | 9000 | 12000 | 22207 | EK |
35 | 72 | 23 | 88.8 | 83 | 9.15 | 9000 | 12000 | 22207 | E |
35 | 80 | 21 | 79.2 | 72 | 8.15 | 7300 | 9500 | 21307 | CCK |
40 | 90 | 38 | 155 | 137 | 14.6 | 3900 | BS2-2308-2RS/VT143 | ||
40 | 90 | 23 | 107 | 108 | 12 | 7000 | 9500 | 21308 | E |
40 | 80 | 23 | 98.5 | 91.5 | 10 | 8000 | 11000 | 22208 | E |
40 | 90 | 33 | 155 | 137 | 14.6 | 6000 | 8000 | 22308 | EK |
40 | 80 | 23 | 98.5 | 91.5 | 10 | 8000 | 11000 | 22208 | EK |
40 | 90 | 23 | 107 | 108 | 12 | 7000 | 9500 | 21308 | EK |
40 | 90 | 33 | 155 | 137 | 14.6 | 6000 | 8000 | 22308 | E |
40 | 80 | 28 | 98.5 | 91.5 | 10 | 3900 | BS2-2208-2RSK/VT143 | ||
40 | 90 | 33 | 155 | 137 | 14.6 | 6000 | 8000 | 22308 | E/VA405 |
40 | 80 | 28 | 98.5 | 91.5 | 10 | 3900 | BS2-2208-2RS/VT143 | ||
45 | 85 | 23 | 104 | 100 | 10.8 | 7500 | 10000 | 22209 | EK |
45 | 100 | 36 | 190 | 176 | 19 | 5300 | 7000 | 22309 | E |
45 | 85 | 28 | 104 | 100 | 10.8 | 3500 | BS2-2209-2RSK/VT143 | ||
45 | 100 | 25 | 129 | 127 | 14 | 6300 | 8500 | 21309 | E |
45 | 100 | 25 | 129 | 127 | 14 | 6300 | 8500 | 21309 | EK |
